A Real Speed Machine
Full-size wheels and performance-tuned frame geometry make it easy to build up and maintain speed as you tackle the roads. Plenty of gears allow you to dial in your most efficient cadence and sprint up hills. Extras like lightweight, aerodynamic Kinetix Pro wheels take things to the next level.
Elevate Your Ride
The Eclipse is a full-featured flat-bar road bike with full-size wheels—that just so happens to fold. We loaded it up with the exact elements needed to create a lightning-fast ride with an amazing feel, all while retaining the versatility and convenience of a folding bike. Folding never rode so fast.
Elegantly Portable and Compact
Living in the city can make it hard to enjoy your bike. From sorting out storage to worrying about theft to wrestling with public transportation—the hurdles are many. The Eclipse provides an elegant solution: a full-size bike that folds surprisingly small, in a matter of seconds and without tools or disassembly.
Eclipse P20
The Eclipse P20 is a high-performance road bike that folds down fast. With custom 26” Rolf Paired Spoke wheels, a 250 mm Physis™ 3D handlepost, and performance-tuned frame geometry, the Eclipse P20 is engineered for speed. It sports a stealth black finish, hydraulic disc brakes, and BioLogic Arx grips.
- Kinetix™ Pro Disc 26” wheels with patented Rolf Paired Spoke design
- Shimano Tiagra drivetrain for 20 speeds and precise, responsive shifting
- Tektro Auriga hydraulic disc brakes for all-weather stopping power
- Adjustable VRO handlebar stem to fine tune your ride position
- High performance Kojak road tires with puncture protection
- Folds compactly in 10 seconds for storage and transport
Eclipse X22
The Eclipse X22 is designed to be the fastest folding bike in the world. With hand-built 26” wheels and race-tuned geometry, it’s a full sized road bike, but it folds down small in 10 seconds. It boasts an Ultegra drivetrain, and—just in time for the UCI’s new regulations—a set of Shimano hydraulic disc brakes. With a stealth black finish, hydroformed fork, red Syntace accents, and perfected engineering, the X22 inaugurates a new chapter in Tern design.
- Kinetix Pro X 26” wheels with straight-pull Sapim spokes for a blazingly fast ride
- Shimano Ultegra / 105 drivetrain for 22 speeds and Grand Tour gear inches
- Shimano hydraulic disc brakes for extreme stopping power
- Adjustable VRO handlebar stem to fine tune your ride position
- High performance Kojak road tires with puncture protection
- SR-71 matte finish
- Fold and store indoors for the best theft protection
Specifications
Eclipse P20 | Eclipse X22 | |
WHEEL SIZES | 26″ wheels | |
SPEEDS | 2 x 10 | 2 x 11 |
WEIGHT | 12.22 kg | 11.3 kg |
GEAR INCHES | 26″ – 112″ (2.09 – 8.92 m) | |
DISTANCE: SEATPOST TO HANDLEBAR | 63 – 70 cm (24.8 – 27.6 in) | 60 – 64 cm (23.6 – 25.2 in) |
DISTANCE: SADDLE TO PEDAL | 77 – 104 cm (30.3 – 40.9 in) | |
SUGGESTED RIDER HEIGHT | 148 – 195 cm (58.3 – 76.8 in) | |
MAX GROSS VEHICLE WEIGHT | 120 kg | |
FRAME | OCL+™ Frame Joint, Tern Eclipse, hydroformed aluminum w/ smooth TIG welding, OCL+ joint, 3 patented technologies, N-Fold™ Technology, DoubleTruss™ Technology | |
FORK | Tarsus™ Fork, Tarsus, 6061-AL, hydroformed | |
HANDLEPOST | Physis™ 3D Handlepost, Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 250 mm | |
STEM | Syntace VRO Stem, Syntace VRO, adjustable | |
HEADSET | Flux, cartridge bearings, Physis integrated | Flux Pro, angular contact bearings, Physis integrated |
HANDLEBAR | Kinetix Comp, 6061-Al, VRO butted | Kinetix™ Pro X Handlebar, Kinetix Pro X, 7050-Al, multi-stage butted |
GRIPS/BAR TAPE | BioLogic Arx | Ergon GP10 L |
SADDLE | Porter+™ Saddle, Tern Porter+, patented GripPad design, PrimeGel padding | Ergon SMC10 Sport Gel |
SEATPOST | SuperOversize, 6061-Al, forged clamp, Pedal Holder | Stasis Seatpost by Syntace, Stasis by Syntace, 7050-AL, hard-anodized |
SEATPOST CLAMP | Syntace OverLock | |
FRONT BRAKE | Tektro Auriga, hydraulic disc | Shimano Deore, hydraulic disc |
REAR BRAKE | Tektro Hydraulic Disk Brakes, Tektro Auriga, hydraulic disc | Shimano Deore Hydraulic Disc Brakes, Shimano Deore, hydraulic disc |
BRAKE LEVERS | Tektro Auriga, hydraulic disc | Shimano Deore, hydraulic disc |
BRAKE CABLE & HOUSING | Tektro Auriga, hydraulic | Shimano, hydraulic |
FRONT WHEEL | Kinetix Pro Disc, Paired Spoke technology, Shimano Centerlock, 20H | Kinetix Pro X Disc, Paired Spoke technology, straight-pull design, 20H, asymmetric flange, 700 g |
REAR WHEEL | Kinetix Pro Disc Wheels, Kinetix Pro Disc Wheels, Kinetix Pro Disc, Paired Spoke technology, Shimano Centerlock, 20H | Kinetix Pro X Disc Wheels, Kinetix Pro X Disc Wheels, Kinetix Pro X Disc, Paired Spoke technology, straight-pull design, 20H, asymmetric flange, 820 g |
SPOKES AND NIPPLES | Double-butted 18/10 stainless, Sapim Polyax nipples | Sapim CX-Sprint, internal Polyax nipples |
TIRES | Schwalbe Kojak Tires, Schwalbe Kojak, 35-559, foldable, puncture protection, 95 psi | |
SHIFTER(S) | Shimano Tiagra trigger, 2×10 spd | Shimano Ultegra trigger, 2×11 spd |
FRONT DERAILLEUR | Shimano Tiagra | Shimano 105 |
REAR DERAILLEUR | Shimano Tiagra | Shimano Ultegra 2 x 11 Drivetrain, Shimano Ultegra |
CRANKSET | FSA Vero, 50/34T | FSA Gossamer Pro, 50/34T, BB386 oversized aluminum spindle, FSA MegaEVO BB386 Crankset |
CASSETTE/FREEWHEEL | Shimano Tiagra 2 x 10 Drivetrain, Shimano Deore, 11-32T, 10 spd | Shimano 105, 11-28T, 11 spd |
BOTTOM BRACKET | Cartridge, sealed bearings | FSA MegaEVO, BB386 |
CHAIN | KMC X10 | Shimano 105, 11 spd |
PEDALS | LiteForm QR, alloy body, QR right/standard left | MKS UB-Lite EZY Pedals, MKS UB-LITE EZY, QR |
SHIFTER CABLE & HOUSING | Jagwire LEX-SL, slick treatment, alloy ferrules | Jagwire LEX-SD, ultra-slick polymer coating, alloy ferrules |
BELL | Pitch, brass | |
KICKSTAND | Premium center mount | |
CLIP SYSTEM | Magnetix™ 2.0 | |
LUGGAGE SOCKET | Yes | |
REAR LIGHT | BioLogic TailLight |
